Key Specifications
Description
SMA Plug (Male) Right Angle Cable Connector for RG 174, DC- 6 GHz, VSWR ≤ 1.35, 50 Ω, with Crimped Cable Entry.
The ROSNOL SMA1C59-G316A/111 is a SMA plug (male) right-angle connector designed for 50 Ω RF cable assemblies operating up to 6 GHz. The right-angle configuration supports compact routing while maintaining stable RF performance. This connector features a screw-lock coupling mechanism to ensure secure mating and reliable signal transmission. A crimped cable entry combined with a soldered center contact provides consistent impedance control and mechanical stability. With a VSWR of ≤ 1.35 and a minimum mating life of 500 cycles, the connector is suitable for space-constrained RF interconnect applications.
The connector body, coupling nut, and crimp ferrule are manufactured from brass with gold plating over a non-magnetic nickel-phosphorus underplating to provide corrosion resistance and long-term durability. A PTFE insulator and silicone rubber gasket support stable dielectric performance. The SMA1C59-G316A/111 is compatible with RG-316/U, RG-174/U, and RG-188/U cables.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities and are fully RoHS and REACH compliant. Customization services for materials, plating, and mechanical design are available upon request.
