1.85mm Femlae Bulkhead Adapter, DC-65 GHz

Order No:AD-V2V25A-BH/9X-9X
Add Cart

Key Specifications

Type Design:
Precision
Connection Type:
In-Series
Connector 1 Series:
1.85mm
Connector 1 Gender:
Jack (Female)
Connector 2 Series:
1.85mm
Connector 2 Gender:
Jack (Female)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
Bulkhead Hexagonal Flange
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
65
Connector 1 Body Material:
Stainless Steel
Connector 1 Body Plating:
Passivated
Connector 2 Body Material:
Stainless Steel
Connector 2 Body Plating:
Passivated
VSWR, Max:
1.25

Description

1.85mm Femlae to 1.85mm Female Bulkhead Adapter, DC-65 GHz, VSWR ≤ 1.25, 50 Ω Impedance.

ROSNOL AD-S1B25A-BHS/933-93 is a bulkhead seal RF adapter that connects an SMB Plug (Male) interface to a BNC Jack (Female) interface. Designed with 50 Ω impedance, DC to 4 GHz frequency coverage, and VSWR ≤ 1.35, it provides reliable RF signal transmission for instrumentation, communication, and industrial applications. The sealed construction helps improve environmental protection and long-term reliability.

The adapter features gold-plated beryllium copper center contacts with non-magnetic nickel-phosphorus underplating and nickel-plated brass bodies for dependable electrical performance and durability. PTFE insulators offer stable dielectric characteristics, while the bulkhead mounting design enables secure panel integration. SMB snap-on and BNC bayonet coupling mechanisms allow quick and reliable connections.

Combining compact SMB connectivity with widely used BNC interfaces, this adapter simplifies RF system integration and maintenance. It is well suited for test equipment, wireless communication devices, industrial control systems, measurement instruments, and general-purpose RF applications requiring dependable signal transfer up to 4 GHz.
