3.5mm Jack (Female) to 3.5mm Jack (Female) Bulkhead Adapter, DC-34.5GHz VSWR 1.15

3.5 mm Jack (Female) to 3.5 mm Jack (Female) | Bulkhead Adapter | Screw-Lock | Stainless Steel Body

The ROSNOL AD-PC2PC25A-BH/9X-9X is a high-performance bulkhead adapter for 50 Ω systems operating from DC to 34.5 GHz. It offers VSWR ≤ 1.15, insertion loss ≤ 0.05 × √f (GHz) dB, insulation resistance ≥ 5 GΩ, test voltage 1000 V rms, and working voltage 335 V rms. RF leakage is ≥ 100 dB up to 1 GHz. The screw-lock coupling ensures secure engagement with ≥ 500 mating cycles, axial captivation ≥ 27 N, and recommended torque between 0.80 and 1.10 Nm.

Materials and plating: center contacts are beryllium copper with gold plating (3 µinch) over a non-magnetic nickel-phosphorus underplate (80 µinch). The body, fastening nut, and washer are stainless steel with passivation for corrosion resistance, and the insulator is PS for stable dielectric properties. Operating temperature range is −55°C to +155°C, ensuring consistent performance in demanding RF environments.

ROSNOL’s precision-engineered RF adapters deliver reliable performance across RF and microwave systems. Designed to meet the stringent demands of high-frequency signal transmission, ROSNOL adapters offer a cost-effective alternative to products from leading European and American brands. All ROSNOL RF components are manufactured in ISO 9001-certified facilities and fully comply with RoHS and REACH regulations. Customization services for materials, plating, and mechanical design are available to support specialized interconnect requirements.
