2.92mm Female Bulkhead Adapter, DC-40 GHz

Order No:AD-K2K25B-BH/9X-9X
Add Cart

Key Specifications

Type Design:
Precision
Connection Type:
In-Series
Connector 1 Series:
2.92mm
Connector 1 Gender:
Jack (Female)
Connector 2 Series:
2.92mm
Connector 2 Gender:
Jack (Female)
Impedance (Ohm):
50
Body Style:
Straight
Panel Mount:
Bulkhead Hexagonal Flange
Connector 1 Connection Method:
Threaded (Screw-lock)
Connector 2 Connection Method:
Threaded (Screw-lock)
Frequency, Max (GHz):
40
Connector 1 Body Material:
Stainless Steel
Connector 1 Body Plating:
Passivated
Connector 2 Body Material:
Stainless Steel
Connector 2 Body Plating:
Passivated
VSWR, Max:
1.15

Description

2.92mm Female to 2.92mm Female Bulkhead Adapter with Sealing, DC-40 GHz, VSWR ≤ 1.15, 50 Ω Impedance.

ROSNOL AD-K2K25B-BH/9X-9X is a 2.92 mm Jack (Female) to 2.92 mm Jack (Female) bulkhead adapter designed for precision RF and microwave applications. Supporting 50 Ω impedance and frequencies from DC to 40 GHz, it delivers VSWR ≤ 1.15, insertion loss ≤ 0.04 × √F (GHz) dB, and RF leakage ≥ 100 dB for excellent signal integrity and shielding performance.

The adapter features beryllium copper center contacts with gold plating over non-magnetic nickel-phosphorus underplating, a passivated stainless-steel body, and a PEI insulator. This construction provides low contact resistance, corrosion resistance, and long-term mechanical stability. The bulkhead design supports secure panel mounting, while the screw-lock coupling mechanism ensures reliable RF connections.

Engineered for microwave communication systems, RF instrumentation, test laboratories, and aerospace electronics, this adapter provides dependable electrical performance and consistent impedance matching in high-frequency interconnect applications.
