Key Specifications
Description
3.5mm Female to Precision N Female Straight Adapter, DC-18 GHz, VSWR ≤ 1.15, 50 Ω Impedance.
ROSNOL AD-PC2PCN25A/9X-9X is a straight RF adapter designed with a 3.5mm jack (female) to Precision N jack (female) interface. Supporting 50 Ω impedance and frequencies from DC to 18 GHz, it delivers VSWR ≤ 1.15 and insertion loss ≤ 0.05 × √F (GHz) dB for accurate, low-reflection signal transmission in demanding RF and microwave applications.
The adapter incorporates beryllium copper center contacts with gold plating over non-magnetic nickel-phosphorus underplating to maintain stable conductivity and low contact resistance. Stainless steel bodies are passivated for excellent corrosion resistance and mechanical strength, while PEI insulators provide reliable dielectric stability across the operating frequency range. Electrical performance includes insulation resistance ≥ 5 GΩ, RF leakage ≥ 90 dB up to 1 GHz, and a 1000 Vrms test voltage rating.
With precision screw-lock coupling interfaces and a durable mechanical design, this adapter ensures repeatable RF performance and secure mating. It is well suited for RF instrumentation, microwave communication systems, antenna measurement platforms, calibration laboratories, and high-frequency test environments requiring dependable interconnection solutions.
