Key Specifications
Description
Precision N Male to 2.92mm Male Straight Adapter, DC-18 GHz, VSWR ≤ 1.15, 50 Ω Impedance.
ROSNOL AD-K1PCN15A/9XX-9XX is a high-performance RF adapter featuring a 2.92 mm Plug (Male) to Precision N Plug (Male) configuration. Designed for 50 Ω systems, it supports frequencies from DC to 18 GHz with VSWR ≤ 1.15 and insertion loss ≤ 0.04 × √F (GHz) dB. This adapter enables accurate signal transmission and impedance matching across microwave communication systems, RF test equipment, and precision measurement applications.
The adapter utilizes stainless steel bodies and coupling nuts with passivated finishes for excellent mechanical strength and environmental durability. Both 2.92 mm and Precision N center contacts are manufactured from beryllium copper and feature gold plating over non-magnetic nickel-phosphorus underplating to ensure low contact resistance and stable electrical performance. PS insulators and silicone rubber gaskets contribute to reliable dielectric characteristics and long-term operation. Screw-lock coupling mechanisms support secure mating with a minimum durability of 500 cycles.
Engineered for demanding microwave environments, the AD-K1PCN15A/9XX-9XX delivers low reflection, excellent signal integrity, and reliable mechanical performance. It is well suited for RF laboratories, microwave instrumentation, aerospace systems, and communication infrastructure requiring precision 2.92 mm-to-Precision N interconnection.
