Key Specifications
Description
SMA Female to SSMA Female Straight Adapter, DC-18 GHz VSWR ≤ 1.2, 50 Ω Impedance.
ROSNOL AD-A2SA25A/9X-9X is a precision RF adapter designed for SMA jack (female) to SSMA jack (female) interface conversion. Operating from DC to 18 GHz in 50 Ω systems, it provides VSWR ≤ 1.20, insertion loss ≤ 0.05 × √F (GHz) dB, RF leakage ≥ 100 dB up to 1 GHz, and power handling up to 200 W at 2 GHz, ensuring reliable signal performance across high-frequency applications.
Both SMA and SSMA interfaces utilize beryllium copper center contacts with gold plating over non-magnetic nickel-phosphorus underplating for excellent electrical conductivity and mating durability. The connector bodies are manufactured from passivated stainless steel, offering superior corrosion resistance and mechanical strength. PTFE insulators provide excellent dielectric stability, while insulation resistance ≥ 5 GΩ and a 1000 Vrms test voltage ensure dependable operation.
Combining low VSWR, high shielding effectiveness, and rugged stainless-steel construction, AD-A2SA25A/9X-9X is ideal for microwave assemblies, RF test equipment, communication infrastructure, aerospace systems, and precision measurement applications requiring reliable SMA-to-SSMA connectivity.
