2.92mm Pulg (Male) to 2.92mm Plug (Male) Cable Assembly for ROSNOL AS40A, DC-40GHz VSWR1.25
Key Specifications
Impedance (Ohm):
50
Frequency, Max (GHz):
40
VSWR, Max:
1.25
Cable Type:
R-Test AS40A
Left Side Series:
2.92mm
Left Side Gender:
Plug (Male)
Left Side Configuration:
Straight
Left Side Panel Mounting:
None
Right Side Series:
2.92mm
Right Side Gender:
Plug (Male)
Right Side Configuration:
Straight
Right Side Panel Mounting:
None
Cable Length:
1000 mm
Description
2.92mm Plug to 2.92mm Plug | AS40A Cable | 1000mm (39.37 inches)
Designed for the most demanding millimeter-wave systems, this Rosnol RF/Microwave cable assembly operates with an impedance of 50 ohms. It maintains an exceptional Voltage Standing Wave Ratio (VSWR) of 1.25 maximum up to 40 GHz, ensuring superior signal integrity and performance. The assembly features 2.92mm Plug (Male) connectors on both ends. Standard available lengths for the AS40A cable include 500 mm (19.69 inches) and 1000 mm (39.37 inches). Insertion loss is precisely controlled to be less than or equal to the value calculated by the formula 0.0023 dB per millimeter multiplied by the cable length in millimeters, plus a fixed factor of 0.1 dB. For specialized requirements beyond the standard offerings, Rosnol provides custom length engineering and manufacturing services to meet precise customer specifications.Rosnol RF/Microwave solutions are manufactured in ISO 9001 Certified Facilities and strictly comply with RoHS and REACH international standards. Our core strength is custom design and manufacturing, guaranteeing cable assemblies precisely tailored to your unique specifications for certified quality and true design flexibility.
