TNC Plug (Male) to Jack (Female) Adapter | Screw-lock | Brass Body
Last Updated: 2026-02-11
The ROSNOL ADL-T1T25C/133-13 is a right-angle TNC adapter designed for RF systems operating up to 11 GHz. It offers 50 Ω impedance, VSWR ≤1.25 (≥19.08 dB), and insertion loss ≤0.05 × √F (GHz) dB. RF leakage is rated <−50 dBi @ 2 GHz and <−45 dBi @ 8 GHz. Mechanical specifications include screw-lock coupling, ≥500 mating cycles, axial captivation ≥15 N, and torque range of 0.46–0.69 Nm.
This adapter features a nickel-plated brass body and coupling nut, brass center contacts with 3 µinch gold plating over 80 µinch non-magnetic nickel-phosphorus underplating, PTFE insulators, and silicone rubber gaskets for optimal dielectric and sealing performance.
ROSNOL’s precision-engineered solutions offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All ROSNOL components are manufactured in ISO 9001-certified facilities and fully comply with RoHS and REACH regulations, ensuring environmental safety and global regulatory alignment. Customization services for materials, plating, and mechanical design are available to support specialized requirements across a wide range of RF and microwave applications.
