Key Specifications
Impedance (Ohm):
50
Frequency, Max (GHz):
40
Outer Diameter(mm):
2.19
Description
50 Ohm Semi-Rigid Coaxial Cable | Tin-Plated Copper Shield | PTFE Dielectric
The ROSNOL RSR-085-TP is a 50 Ohm semi-rigid coaxial cable designed for microwave applications up to 40 GHz. It features a steel inner conductor plated with copper and silver (∅0.51 mm / 0.0201 in), PTFE dielectric (∅1.68 mm / 0.0661 in), and a tin-plated copper outer shield (∅2.19 mm / 0.0862 in). With a minimum bending radius of 3.2 mm (0.1260 in) and weight of 20.2 g/100m, the cable supports operating temperatures from -40°C to +125°C.Electrical specifications include 95.1 pF/m capacitance, 69.5% signal velocity, and operating voltage up to 1.5 kVrms. Typical attenuation ranges from 0.49 dB/m at 0.5 GHz to 6.62 dB/m at 40 GHz, with maximum CW power handling of 209 W at lower frequencies. The RSR-085-TP is RoHS compliant and suitable for high-frequency RF systems requiring stable performance and enhanced shielding.
ROSNOL’s cable solutions are precision-engineered to meet the rigorous demands of RF and microwave transmission systems. Manufactured under ISO 9001-certified processes, ROSNOL cables deliver consistent high quality and performance at competitive pricing, making them a reliable alternative to products from leading European and American brands. All ROSNOL cables are fully compliant with global environmental and safety regulations, including RoHS and REACH. Customization services for materials, shielding, and mechanical design are available to support specialized application requirements.
