TNC Jack (Female) Cable Connector for LMR-400, RNL-400, RG-213, RG-214, DC-6GHz VSWR1.30
Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
6.0
VSWR, Max:
1.30
Connector Series:
TNC
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Cable Entry:
Clamped
Mount Method:
None
Body Material:
Brass
Body Plating:
Copper-Tin Zinc Alloy
Captivated Type:
Mechanical Captivation
Suitable Cables:
RG-214(214/U)
Description
TNC Jack (Female) | Clamped Cable Entry | Screw-lock | Brass Body*
The ROSNOL TNC2D50-R400A/H4 is a straight TNC jack engineered for high-power RF applications. Designed with a 50 Ω impedance and operating up to 6 GHz, it delivers consistent performance with VSWR ≤ 1.30 (≥ 17.69 dB). The connector features a screw-lock coupling mechanism, a soldered centre contact, and a clamped cable entry. The overall body length is 35.2 mm [1.386"], with wrench flats of 12 mm [0.472"] and 15.8 mm [0.622"].Constructed with a brass body and phosphor bronze centre contact, the connector is plated with copper-tin-zinc alloy and gold over nickel respectively. It includes a PTFE insulator, silicone rubber gasket, and a brass clamp nut with copper-tin-zinc alloy plating. Compatible with Times LMR 400, ROSNOL RNL 400, RG 213, and RG 214 cables.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
