TNC Plug (Male) Cable Connector for LMR-400, RNL-400, RG-213, RG-214, DC-6GHz VSWR 1.30
Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
6.0
VSWR, Max:
1.30
Connector Series:
TNC
Connector Gender:
Plug (Male)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Cable Entry:
Clamped
Mount Method:
None
Body Material:
Brass
Body Plating:
Copper-Tin Zinc Alloy
Captivated Type:
Mechanical Captivation
Suitable Cables:
RG-214(214/U)
Description
TNC Plug (Male) | Clamped Cable Entry | Screw-lock | Brass Body
The ROSNOL TNC1D50-R400A/144 is a robust TNC straight cable plug engineered for 50 Ω RF systems from DC to 6 GHz. It features a screw-lock coupling mechanism and clamped cable entry, with a soldered centre contact for reliable signal transmission. VSWR is ≤ 1.30 (≥ 17.69 dB), and the connector operates effectively from -65°C to +165°C.This connector includes a brass body and coupling nut with copper-tin-zinc alloy plating, PTFE insulator, and a gold-plated brass centre contact (nickel underplated). Clamp nut is also made of copper-tin-zinc alloy. Compatible with Times Microwave LMR400, ROSNOL RNL400, RG213, and RG214 cables. Crimp dimensions follow DIN ISO 2768-mH standards.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
