Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
4.0
VSWR, Max:
1.09
Connector Style:
Panel Connector
Connector Series:
TNC
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
4 Hole Flange
Body Material:
Stainless Steel
Body Plating:
Passivated
Captivated Type:
Mechanical Captivation
Bankend Type:
Coaxial End
Description
TNC Jack Panel Connector | Stainless Steel Body | Stub Terminal | Mechanical Captivation
The ROSNOL TNC2GFA50-2940A/HX is a high-performance TNC Jack Panel Connector designed for demanding RF applications. Engineered with a 50 Ω impedance and supporting frequencies from DC to 4 GHz, this connector ensures reliable signal transmission. It features a 4-hole flange mount with 12.7mm (.500 inch) hole spacing and a screw-lock coupling mechanism. With a VSWR ≤ 1.09 (≥ 27 dB), the connector delivers excellent return loss performance, making it ideal for precision RF systems.The ROSNOL TNC2GFA50-2940A/HX is constructed using premium materials to ensure durability and optimal electrical performance. Its center contact is made of phosphor bronze with 3 µinch gold plating over 80 µinch non-magnetic nickel-phosphorus underplating. The body is crafted from stainless steel with passivation treatment, while the insulator is PTFE and the gasket is silicone rubber. This robust material combination guarantees long-term reliability in harsh environments.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
