Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
4.0
VSWR, Max:
1.09
Connector Style:
Panel Connector
Connector Series:
TNC
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
4 Hole Flange
Body Material:
Brass
Body Plating:
Nickel
Captivated Type:
Mechanical Captivation
Bankend Type:
Coaxial End
Description
TNC Jack (female) Panel Connector | Brass Body | Stub Terminal | Mechanical Captivation
The ROSNOL TNC2GFA50-2880D/H3 is a high-performance TNC Jack (female) Panel Connector designed for demanding RF applications. Featuring a Stub terminal and Mechanical captivation, this connector supports 50 Ω impedance and operates across a wide frequency range from DC to 4 GHz. With a Screw-lock coupling mechanism and precise 12.7mm (.500 inch) hole spacing, it ensures reliable connectivity and minimal signal loss. The VSWR/Return Loss performance of ≤ 1.09 (≥ 27 dB) guarantees optimal transmission quality in high-frequency environments.Constructed with premium materials, the ROSNOL TNC2GFA50-2880D/H3 offers durability and superior electrical performance. The centre contact is made of Phosphor Bronze, Gold plating 3 µinch (Nickel-phosphorus underplating 80 µinch), while the body is crafted from Brass, Nickel. An insulating layer of PTFE and a sealing gasket of Silicone Rubber ensure stability and environmental protection. The connector's plating and material choices are optimized for longevity and consistent RF performance.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
