Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.30
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
2 Hole Flange
Body Material:
Brass
Body Plating:
Gold Plating (Nickel underplated)
Captivated Type:
Epoxy Captivation
Bankend Type:
Coaxial End
Description
SMA Female Connector with Stub Terminal | Solder Attachment | Brass Body | Epoxy Captivation
The ROSNOL SMA2GTA50-2600A-EC/91 RF Connector features a 50Ω impedance and operates across a wide frequency range from DC to 18 GHz. Designed with a 2-hole flange mount and stub terminal, it offers a hole spacing of 12.22mm (0.481 inch). The connector ensures excellent signal integrity with a VSWR ≤ 1.30 (≥ 17.7 dB) and insertion loss ≤ 0.05√F(GHz) dB. Its screw-lock coupling mechanism supports ≥ 500 mating cycles, and it withstands up to 1000 V rms test voltage. Constructed with a brass body and beryllium copper center contact, both gold-plated over nickel, and PTFE insulation, it guarantees durability and performance.ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
