Key Specifications
Description
SMA Female Connector, 2 Hole Flange Mount, Stub Terminal, 12.22 mm Hole Spacing, 50 Ω, DC-18 GHz VSWR ≤1.30.
ROSNOL SMA2GTA50-2540A/91 is a precision SMA Jack (Female) connector engineered for RF and microwave applications requiring secure panel-mounted connectivity. This 50 Ohm connector features a solder attachment interface, 2-hole flange mount configuration, and stub terminal design with 12.22 mm (0.481 inch) hole spacing. Operating from DC to 18 GHz, it delivers a VSWR of ≤ 1.30 and insertion loss of ≤ 0.05 × √F (GHz) dB, helping maintain reliable signal integrity across a broad frequency range. Additional electrical specifications include insulation resistance of ≥ 5 GΩ, center contact resistance of ≤ 3 mΩ, and power handling capability up to 200 W at 2 GHz.
The connector utilizes a beryllium copper center contact with gold plating over non-magnetic nickel-phosphorus underplating to ensure low contact resistance and long-term reliability. The body is manufactured from brass with matching gold plating and underplating, while a PTFE insulator provides stable dielectric performance. Mechanical features include a screw-lock coupling mechanism, soldered center contact, mechanical captivation structure, and mating durability of at least 500 cycles. The connector is designed to operate from -65°C to +165°C, supporting dependable performance in demanding environments.
This SMA Jack (Female) RF connector is suitable for RF communication systems, microwave modules, wireless infrastructure, antenna assemblies, signal distribution equipment, and laboratory measurement instruments. Its durable plated construction, secure flange-mount design, and DC-18 GHz frequency coverage make it a dependable RF interconnect solution for professional applications.
