Key Specifications
Description
SMA Female Connector with Stub Terminal | Solder Attachment | Stainless Steel Body | Epoxy Captivation
The ROSNOL SMA2GTA50-2200A-EC/9X is a high-performance SMA Jack (Female) RF Connector engineered for demanding RF and microwave applications. This 50 Ω impedance connector operates across a broad frequency range from DC to 18 GHz. It features a low VSWR of (17.7 dB Return Loss) and is designed for secure solder attachment with a 2-hole flange mount and 12.22mm (.481 inch) hole spacing. The robust screw-lock coupling mechanism ensures reliable connections.
Constructed with a beryllium copper center contact with gold plating and a passivated stainless steel body, alongside a PTFE insulator, this ROSNOL RF connector delivers exceptional electrical performance and mechanical durability. The stub terminal and epoxy captivation provide enhanced contact stability, crucial for applications requiring resistance to vibration and shock. It is rated for mating cycles and has a working voltage of 480 V rms at sea level.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All ROSNOL RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
