Key Specifications
Description
SMA Female Connector, 2 Hole Flange Mount, Stub Terminal, 12.22 mm Hole Spacing, 50 Ω, DC-18 GHz VSWR ≤1.30.
ROSNOL SMA2GTA50-2000A/91 is a high-performance SMA Jack (Female) connector developed for RF and microwave applications requiring secure panel integration and stable signal transmission. Featuring a solder attachment interface, 2-hole flange mount design, and stub terminal structure, this 50 Ohm connector utilizes 12.22 mm (0.481 inch) hole spacing for standardized installation. The connector operates from DC to 18 GHz with a VSWR of ≤ 1.30 and insertion loss of ≤ 0.05 × √F (GHz) dB. Electrical specifications also include insulation resistance of ≥ 5 GΩ, center contact resistance of ≤ 3 mΩ, and power handling capability up to 200 W at 2 GHz.
The center contact is fabricated from beryllium copper with gold plating over non-magnetic nickel-phosphorus underplating, while the body is constructed from brass with gold plating and matching underplating. A PTFE insulator provides dependable dielectric stability. Mechanical features include a screw-lock coupling mechanism, soldered center contact, mechanical captivation design, and durability of at least 500 mating cycles. The connector is rated for operation from -65°C to +165°C, supporting reliable performance in challenging environmental conditions.
This SMA Jack (Female) RF connector is ideal for wireless communication systems, microwave assemblies, RF instrumentation, antenna equipment, test platforms, and signal routing applications. Its combination of broad frequency coverage, gold-plated conductive surfaces, and robust flange-mount construction provides a dependable RF connectivity solution for professional electronic systems.
