Key Specifications
Description
SMA Female Connector, 2 Hole Flange Mount, Stub Terminal, 12.22 mm Hole Spacing, 50 Ω, DC-18 GHz VSWR ≤1.30.
ROSNOL SMA2GTA50-1850A/91 is a precision SMA Jack (Female) connector engineered for RF and microwave applications requiring reliable panel-mounted connectivity and stable signal transmission. This 50 Ohm connector features a solder attachment interface, 2-hole flange mount configuration, and stub terminal design with 12.22 mm (0.481 inch) hole spacing. Operating from DC to 18 GHz, it delivers a VSWR of ≤ 1.30 and insertion loss of ≤ 0.05 × √F (GHz) dB, supporting excellent electrical performance across a broad frequency range. Additional specifications include insulation resistance of ≥ 5 GΩ, center contact resistance of ≤ 3 mΩ, and power handling capability up to 200 W at 2 GHz.
The connector utilizes a beryllium copper center contact with gold plating over non-magnetic nickel-phosphorus underplating to ensure excellent conductivity and long-term reliability. The body is manufactured from brass with gold plating and matching underplating, while a PTFE insulator provides stable dielectric performance. Mechanical features include a screw-lock coupling mechanism, soldered center contact, mechanical captivation structure, and mating durability of at least 500 cycles. Designed for demanding environments, the connector operates across a temperature range of -65°C to +165°C.
This SMA Jack (Female) RF connector is suitable for RF communication systems, wireless infrastructure, microwave equipment, antenna interfaces, test and measurement instruments, and electronic signal routing assemblies. Its reliable flange-mount architecture, broad DC-18 GHz frequency coverage, and durable plated construction provide a dependable RF interconnect solution for professional high-frequency applications.
