Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.30
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
4 Hole Flange
Body Material:
Brass
Body Plating:
Gold Plating (Non-magnetic nickel-phosphorus underplating)
Captivated Type:
Epoxy Captivation
Bankend Type:
Flat End
Description
SMA Female | Screw-lock | Epoxy Captivation
The ROSNOL SMA2GFD50-1200A-EC/91 is a 50 Ω impedance SMA female connector with a flat terminal and 8.64 mm (.340 inch) hole spacing. It features a screw-lock coupling mechanism and a soldered beryllium copper center contact. The terminal type is flat, and the connector uses epoxy captivation for secure contact retention.The body is made of brass with gold plating over 80 µinch non-magnetic nickel-phosphorus underplating. The center contact is gold-plated beryllium copper, and the insulator is PTFE, providing excellent electrical insulation.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
