Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.30
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
4 Hole Flange
Body Material:
Stainless Steel
Body Plating:
Passivated
Captivated Type:
Epoxy Captivation
Bankend Type:
Coaxial End
Description
SMA Female | Screw-lock | Epoxy Captivation
The ROSNOL SMA2GFA50-4240B-EC/9X is a precision RF connector with 50 Ω impedance and a 4-hole flange mount featuring 6.35 mm (.250 inch) hole spacing. It employs a screw-lock coupling mechanism and a soldered beryllium copper center contact. The stub terminal is epoxy captivated, offering axial retention ≥ 27 N and radial retention ≥ 3 Ncm.This connector is built with a stainless steel body and passivated finish. The center contact is gold-plated with nickel underplating, and the insulator is made of PTFE for reliable RF insulation.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
