Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.30
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
4 Hole Flange
Body Material:
Stainless Steel
Body Plating:
Passivated
Captivated Type:
Epoxy Captivation
Bankend Type:
Coaxial End
Description
SMA Female connector | Stainless Steel body | Epoxy Captivation
The ROSNOL SMA2GFA50-2540A-EC/9X features a 50 Ω impedance and a 4 Hole Flange with 8.64mm (.340 inch) hole spacing. It utilizes a screw-lock coupling mechanism and includes a soldered centre contact. The terminal type is Stub, and the captivated type is Epoxy Captivation.Constructed with high-quality materials, the centre contact is made of Beryllium Copper with Gold plating, 3 µinch (Non-magnetic nickel-phosphorus underplating, 80 µinch). The body is composed of Stainless Steel with Passivated. The insulator is PTFE.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
