Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.30
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
4 Hole Flange
Body Material:
Stainless Steel
Body Plating:
Gold Plating (Non-magnetic nickel-phosphorus underplating)
Captivated Type:
Epoxy Captivation
Bankend Type:
Coaxial End
Description
SMA Female Connector | Stub Terminal | Stainless Steel Body | Epoxy Captivation
The ROSNOL SMA2GFA50-2000A-EC/9Q is a high-performance RF Connector with an impedance of 50 Ω. It features a 4 Hole Flange design with 8.64mm (.340 inch) hole spacing. The connector utilizes a Screw-lock coupling mechanism and includes a Soldered centre contact. Designed with a Stub terminal type and Epoxy Captivation captivated type, it ensures reliable mechanical stability and electrical performance.The connector body is constructed from Stainless Steel with Gold plating (Nickel underplated). The centre contact is made of Beryllium Copper and finished with Gold plating (Nickel underplated). The insulator is made of PTFE, providing excellent dielectric properties.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
