Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.25
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
4 Hole Flange
Body Material:
Stainless Steel
Body Plating:
Passivated
Captivated Type:
Mechanical Captivation
Bankend Type:
Coaxial End
Description
SMA Female Connector with Coaxial End | Stainless Steel Body | Straight Panel Mount
The ROSNOL SMA2GFA50-1395B/9X is a straight panel receptacle jack designed for SMA female coaxial applications. It supports a 50 Ω impedance and operates across DC to 18 GHz with a VSWR ≤ 1.25. The connector features a screw-lock coupling mechanism and a coaxial end centre contact. Terminal type is coaxial, and the captivated type is mechanical.This model is built with a stainless steel body and passivated finish. The centre contact is beryllium copper with gold plating over nickel underplating. The insulator is PTFE, ensuring reliable electrical insulation and performance.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
