Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.25
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Jack (Female)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
4 Hole Flange
Body Material:
Brass
Body Plating:
Gold Plating (Nickel underplated)
Captivated Type:
Epoxy Captivation
Bankend Type:
Coaxial End
Description
SMA Female Connector with Coaxial End | Panel Mount | Brass Body
The ROSNOL SMA2GFA50-1300B-EC/91 is a straight SMA female panel receptacle designed for DC to 18 GHz applications. It features a 50 Ω impedance and a screw-lock coupling mechanism. The connector terminates with a coaxial end and includes epoxy captivated centre contact for enhanced mechanical stability.This model is constructed with a brass body and gold plating, while the centre contact is made of beryllium copper with gold plating over nickel underplating. The insulator is PTFE, ensuring reliable dielectric performance across a wide temperature range of -65°C to +165°C.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
