SMA Male Connector, 2 Hole Flange, DC-18 GHz

Order No:SMA1GTA50-1910A-EC/111
Add Cart

Key Specifications

Type Design:
Standard
Impedance (Ohm):
50
Body Style:
Straight
Frequency, Max (GHz):
18
VSWR, Max:
1.30
Connector Series:
SMA
Connector Gender:
Plug (Male)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
2 Hole Flange
Body Material:
Brass
Body Plating:
Gold Plating (Non-magnetic nickel-phosphorus underplating)
Captivated Type:
Epoxy Captivation
Bankend Type:
Coaxial End

Description

SMA Male Connector, 2 Hole Flange Mount, Stub Terminal, 12.2 mm Hole Spacing, 50 Ω, DC- 18 GHz VSWR ≤ 1.30.

The ROSNOL SMA1GTA50-1910A-EC/111 is a precision SMA plug (male) connector with solder attachment, 2-hole flange mount, and stub terminal featuring 12.22 mm (0.481 inch) hole spacing. This RF interconnect provides 50 Ω impedance from DC to 18 GHz, delivering VSWR of ≤ 1.30 and insertion loss of ≤ 0.05 × √F (GHz) dB. Built to IEC 61169-15 specifications, it ensures consistent high-frequency performance for standard SMA applications.

The connector body, coupling nut, and center contact are all fabricated from brass with gold plating over non-magnetic nickel-phosphorus underplating. A PTFE insulator and silicone rubber gasket maintain dielectric stability and sealing. Epoxy captivation secures the center contact, and screw-lock coupling supports ≥ 500 mating cycles. The temperature range covers –65 °C to +165 °C, and the product is RoHS compliant.

This SMA flange-mount plug is suited for microwave test equipment, RF modules, communication systems, and precision instrumentation operating up to 18 GHz. Its all-brass gold-plated construction, reliable electrical performance, and epoxy captivation provide dependable interconnect solutions for RF engineers seeking consistent results in standard frequency applications.
