Key Specifications
Type Design:
Standard
Body Style:
Straight
Impedance (Ohm):
50
Frequency, Max (GHz):
18
VSWR, Max:
1.30
Connector Style:
Panel Connector
Connector Series:
SMA
Connector Gender:
Plug (Male)
Connection Method:
Threaded (Screw-lock)
Center Contact:
Soldered
Mount Method:
2 Hole Flange
Body Material:
Stainless Steel
Body Plating:
Passivated
Captivated Type:
Mechanical Captivation
Bankend Type:
Coaxial End
Description
SMA Male Connector with Stub Terminal | Extended Profile | Stainless Steel Housing
The SMA1GTA50-1910A/1XX is a rugged SMA male connector designed with a screw-lock coupling mechanism rated for ≥ 500 mating cycles. It includes a soldered centre contact, stub terminal type, and mechanical captivated structure with axial retention ≥ 27 N and radial retention ≥ 3 Ncm, providing reliable mechanical stability.This model features a stainless steel body and coupling nut (passivated), brass centre contact with 3 µinch gold plating over 80 µinch non-magnetic nickel-phosphorus underplating, PTFE insulator, and silicone rubber gasket. Its extended mechanical profile enhances robustness for high-frequency and vibration-prone environments.
ROSNOL’s precision-engineered RF connectors offer a competitive alternative to products from leading manufacturers in Europe, the USA, and other global markets. All Rosnol RF components are precision-manufactured in ISO 9001-certified facilities, and are fully RoHS and REACH compliant, ensuring environmental safety and global regulatory alignment. Customization services for plating, materials, and mechanical design are available upon request.
