Order No	Product Name	Type Design	Impedance (Ohm)	Body Style	Frequency, Max (GHz)	VSWR, Max	Connector Series	Connector Gender	Connection Method	Center Contact	Cable Entry	Mount Method	Body Material	Body Plating	Captivated Type	Suitable Cables
SMA7C50-G058A_14	SMA R/P Female Cable Connector for RG141, 12.4 GHz	Standard	50	Straight	12.4	N/A	SMA	R/P Jack (Female)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-141
SMA7C50-G058A_14	SMA R/P Female Cable Connector for RG400, 12.4 GHz	Standard	50	Straight	12.4	N/A	SMA	R/P Jack (Female)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-400
SMA7C50-G058A_14	SMA R/P Female Cable Connector for RG223, 12.4 GHz	Standard	50	Straight	12.4	N/A	SMA	R/P Jack (Female)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-223
SMA7C50-G058A_14	SMA R/P Female Cable Connector for RG142, 12.4 GHz	Standard	50	Straight	12.4	N/A	SMA	R/P Jack (Female)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-142
SMA7C50-G058A_14	SMA R/P Female Cable Connector for RG58, 12.4 GHz	Standard	50	Straight	12.4	N/A	SMA	R/P Jack (Female)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-58
SMA7C50-G058A_11	SMA R/P Female Cable Connector for RG58, 12.4 GHz	Standard	50	Straight	12.4	N/A	SMA	R/P Jack (Female)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Gold Plating (Non-magnetic nickel-phosphorus underplating)	Mechanical Captivation	RG-58
SMA7C50-G142A/11	SMA R/P Female Cable Connector for RG142, 6 GHz	Standard	50	Straight	6.0	N/A	SMA	R/P Jack (Female)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	RG-142
SMA5C59-G058A/944	SMA RP Male RA Cable Connector for RNL195, 3GHz	Standard	50	Right Angle	3.0	1.20	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	ROSNOL RNL-195
SMA5C59-G058A/944	SMA RP Male RA Cable Connector LMR195, 3GHz	Standard	50	Right Angle	3.0	1.20	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-195
SMA5C59-G058A/944	SMA RP Male RA Cable Connector for Belden 9907, 3GHz	Standard	50	Right Angle	3.0	1.20	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 9907
SMA5C59-G058A/944	SMA RP Male RA Cable Connector for Belden 7806A, 3GHz	Standard	50	Right Angle	3.0	1.20	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden 7806A
SMA5C59-G058A/944	SMA RP Male RA Cable Connector for RG303, 3GHz	Standard	50	Right Angle	3.0	1.20	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-303
SMA5C59-G058A/944	SMA RP Male RA Cable Connector for RG141, 3GHz	Standard	50	Right Angle	3.0	1.20	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-141
SMA5C59-G058A/944	SMA RP Male RA Cable Connector for RG58C, 3GHz	Standard	50	Right Angle	3.0	1.20	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-58C
SMA5C59-G058A/944	SMA RP Male RA Cable Connector for RG58A, 3GHz	Standard	50	Right Angle	3.0	1.20	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-58A
SMA5C59-G058A/944	SMA RP Male RA Cable Connector for RG58, 3GHz	Standard	50	Right Angle	3.0	1.20	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	RG-58
SMA5C50-R240A/H44	SMA R/P Male Cable Connector for RNL240, 6 GHz	Standard	50	Straight	6.0	N/A	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	ROSNOL RNL-240
SMA5C50-R240A/H44	SMA R/P Male Cable Connector for Belden H155, 6 GHz	Standard	50	Straight	6.0	N/A	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden H155
SMA5C50-R240A/H44	SMA R/P Male Cable Connector for LMR240, 6 GHz	Standard	50	Straight	6.0	N/A	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-240
SMA5C50-R240A/944	SMA R/P Male Cable Connector for RNL240, 6 GHz	Standard	50	Straight	6.0	N/A	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	ROSNOL RNL-240
SMA5C50-R240A/944	SMA R/P Male Cable Connector for Belden H155, 6 GHz	Standard	50	Straight	6.0	N/A	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	Belden H155
SMA5C50-R240A/944	SMA R/P Male Cable Connector for LMR240, 6 GHz	Standard	50	Straight	6.0	N/A	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Copper-Tin Zinc Alloy	Mechanical Captivation	LMR-240
SMA5C50-R240A/911	SMA R/P Male Cable Connector for RNL240, 6 GHz	Standard	50	Straight	6.0	N/A	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	ROSNOL RNL-240
SMA5C50-R240A/911	SMA R/P Male Cable Connector for Belden H155, 6 GHz	Standard	50	Straight	6.0	N/A	SMA	R/P Plug (Male)	Threaded (Screw-lock)	Crimped or Soldered	Crimped	None	Brass	Gold Plating (Nickel underplated)	Mechanical Captivation	Belden H155
