Product Details

BNC Plug (Male) Straight Cable Connector

Order No:BNC1D50-R400A/144
Product Name:Cable Clamp
Series:BNC
Gender:Plug (Male)
Configuration:Straight
Suitable Cable:RG-214
Backend Type:Cable Clamp
Application Field:Communication
Rsonl P/N:BNC1D50-R400A/144

Product Introduction

The BNC1D50-R400A/144 is a BNC male coaxial connector with an interface type that suits LMR-400, RNL-400, RG-213 and RG-214. Its attachment method is solder or crimp for the pin and clamp for the cable. This connector design has an impedance of 50 Ohm and is fully compliant to RF industry standards. It has a straight connector configuration.

The BNC2D50-R400A/144 has a brass pin with gold plating (nickel underplated) and a brass body with copper-tin-zinc alloy plating. Similar to almost all of our countless other millimeter wave, microwave and RF components, our BNC plug coaxial connector is in full compliance with RoHS (Directive 2011/65/EU) and REACH (EC 1907/2006).

Rosnol's BNC1D50-R400A/144 male BNC RF connector has a maximum frequency of 4 GHz and a max. VSWR of 1.30 or min. Return Loss of 17.69 dB. As a result, this high-quality cable connector is a good alternative to the interconnect product choices from competitors from Europe, the USA, or other markets.

Rosnol's millimeter wave, microwave and radio frequency products are precision manufactured in and shipped from its ISO certified (ISO9001) factory. Customization (material, plating, body, etc.) is possible upon request.

LMR is a Trademark of Times Microwave
